Designed for compatibility with any manufacturer’s products, our Swivel Joints ensure a precise fit, giving you confidence in their reliability and performance.
Crafted from high-tensile alloy steel, our swivel joints are built to withstand harsh environments, making them ideal for fracturing, cementing, acidizing, and other high-pressure applications.
RDI’s swivel joints are engineered with high-quality materials and customizable configurations to maximize efficiency and ensure seamless operation on your job site.
| Swivels (Style) | Size | Configuration | Pressure Rating MAWP | Male (Wing) & Female (Thread) |
| Style 10 | 2″ | 1502 | 15,000PSI | MxF & MxM |
| 3″ | 1502 | 15,000PSI | MxF & MxM | |
| 4″ | 1002 | 10,000PSI | MxF & MxM | |
| Style 20 | 2″ | 1502 | 15,000PSI | MxF |
| 3″ | 1502 | 15,000PSI | MxF | |
| 4″ | 1002 | 10,000PSI | MxF | |
| Style 30 | 2″ | 1502 | 15,000PSI | MxF |
| 3″ | 1502 | 15,000PSI | MxF | |
| 4″ | 1002 | 10,000PSI | MxF | |
| Style 50 | 2″ | 1502 | 15,000PSI | MxF |
| 3″ | 1502 | 15,000PSI | MxF | |
| 4″ | 1002 | 10,000PSI | MxF | |
| Style 60 | 2″ | 1502 | 15,000PSI | MxF MxM |
| 3″ | 1502 | 15,000PSI | MxF | |
| Style 80 | 2″ | 1502 | 15,000PSI | MxF |
| 3″ | 1502 | 15,000PSI | MxF | |
| 4″ | 1002 | 10,000PSI | MxF | |
| Style 100 | 2″ | 1502 | 15,000PSI | MxF |
| 3″ | 1502 | 15,000PSI | MxF |
High-pressure well-servicing lines, fracturing lines, testing lines, cementing and circulating lines, and other well service and stimulation applications
